The beamsplitter is a device for dividing an incident beam into two beams in two different directions. Beamsplitters come with different kind of shapes, coating and processing way. Such as cubes, plates, polarizing, non -polarizing,dielectric, air-spaced.
Coligh would offer you plate and lens splitters with air-spaced coating.
Product portfolio: single point wavelength beamsplitter, wide band splitter, Polarizing Beamsplitter Prism, Depolarizing Beamsplitter Prism.
Production capability:
Size:Custom by client’s requirement
Thickness: 0.35mm-5mm
Wavelength range: 250-1700nm (UV, NIR, IR)
R/T & T/R: 50:50/70:30/30:70/20:80/80:20
Size and thickness allowance: +/-0.1mm
Scratch dig: 60-40, 40-20
Substrate: B270, float glass, K9, BK7
